24V 4000VA (3600W) Hybrid Inverters ■ Three in one：This is a multi-function inverter/charger that combines functions of an inverter . solar charger and battery charger to provide uninterrupted power supply with portable size. ■ LCD screen：Its comprehensive LCD display provides user-configurable and easily accessible key controls such as battery charging current . AC/solar charging priority and acceptable input voltage based on various applications. ■ ON/Off-grid inverters：The island grid inverter can operate autonomously after leaving the power grid. It corresponds to an independent small power grid. It mainly controls its own voltage and is a voltage source. It can transport ohmic capacitive and motor inductive loads . has fast response and anti-interference . high adaptability and practicality . and is the power supply product of first choice for emergency power supply in case of power failure and outdoor power supply.
  • 【All-in-one solar charge inverter】3600W Solar Inverter 24V DC to 110V/120V AC . built-in 120A MPPT charge controller .fit for 24V Lead-Acid (Seal . AGM .Gel . Flooded) and Lithium battery. The solar charge module adopts the latest optimized MPPT tracking technology . with an efficiency of up to 98%.
  • 【TECHNICAL SPECIFICATIONS】3600VA Hybrid Solar Inverter Max.PV Input Power: 4200W . Voltage range: 60-500Vdc . Max. PV Input VOC: 500V DC;charge current: 120A.Nominal Input Frequency: 60Hz; Output Power: 3600W . surge Capacity: 7200W.
  • 【MULTIPLE CHARGING MODES】Off Grid Solar Inverter have 4 charging modes are optional . i.e. Only Solar . Mains First . Solar First and Mains & Solar hybrid charging;and 3 output modes are available . i.e. Solar First . Mains First and SBU Priority . uninterrupted power supply to meet different application requirements. And compatible to mains voltage or generator power . Auto restart while AC is recovering
  • 【LCD & LED DISPLAY】LCD display design and 3 LED indicators for dynamic display of system data and operating status . Configurable battery charging current . AC/Solar Charger priority and Load Supply Priority via LCD setting.Support WIFI remote monitoring .available for IOS and Android . users can monitor the status of the PV system from the mobile phone or from the website anytime anywhere. (Not included)
  • 【WIDE RANGE OF USES】MPPT Inverter Charger Pure sine Wave 3600W for RV Camping Boat Home Emergency etc.. Can be accessed to a variety of household and office loads . including Oven . rice cooker . lamps . televisions . fans and other AC loads.you can enjoy the stable power from the sun and the utility grid to keep you powered under any circumstances.
  • 📘MODEL：ECO-3.6KW
    Phase：1-phase
    Maximum PV Input Power：4200W
    Rated Output Power：3600W/3600VA(3000/3150/3300)
    Maximum Solar Charging Current：120A
    📘GRID-TIE OPERATION
    PV INPUT(DC)
    Nominal DC Voltage/MaximumDC Voltage：360/500VDC
    Start-up Voltage/Initial Feeding Voltage：60VDC/90VDC
    MPPT Voltage Range：60~450VDC
    Maximum Input Current：1/18A
    GRID OUTPUT (AC）
    Nominal Output Voltage：120VAC(100/105/115V settable)
    Output Voltage Range：90-150VDC
    Nominal Output Current：30A
    Power Factor：>0.99
    EFFICIENCY
    Maximum Conversion Efficiency (DC/AC)：98%
    TWO LOAD OUTPUT POWER
    Full Load：3600W
    Maximum Main Load：3600W
    Maximum Second Load(battery mode)：1200W
    Maximum Load Cut Off Voltage：26VDC
    Maximum Load Return Voltage：27VDC

  • 📘OFF-GRID OPERATION
    AC INPUT
    AC Start-up Voltage/Auto Restart Voltage：110VAC/120VAC
    Acceptable Input Voltage Range：90~145AC±2%
    Frequency Range：49~51±1HZ
    Maximum AC Input Current：40A
    PV INPUT(DC)
    Nominal DC Voltage/Maximum DC Voltage：360/500VDC
    MPPT Voltage Range：60-450VDC
    Maximum Input Current：1/18A
    BATTERY MODE OUTPUT(AC)
    Nominal Output Voltage：120VAC(100/105/115V settable)
    Output Waveform：Pure sine wave
    Efficiency(DC to AC)： 94%
    BATTERY & CHARGER
    Nominal DC Voltage：24VDC
    Maximum Solar Charging Current：120A
    Maximum AC Charging Current：100A
    Maximum Solar+AC Charging Current：120A

  • 📘HYBRID OPERATION
    PV INPUT(DC)
    Nominal DC Voltage/Maximum DC Voltage：360/500VDC
    Start-up Voltage/Initial Feeding Voltage：90VDC/120VDC
    MPPT Voltage Range：60~450VDC
    Maximum Input Current：1/18A
    GRID OUTPUT(AC)
    Nominal Output Voltage：120VAC(100/105/115V settable)
    Output Voltage Range：60-450VDC
    Nominal Output Current：30A
    AC INPUT
    AC Start-up Voltage /Auto Restart Voltage：120-140VAC/180VAC
    Acceptable Input Voltage Range：90-280VAC or 170-280VAC
    Maximum AC Input Current：40A
    Maximum Charging Current：120A

  • GENERAL
    PHYSICAL
    Dimension .D*W*H(mm)：420*350*110
    Cartoon Dimension .D*W*H(mm)：500*415*180
    Net Weight(kgs)：8.8
    Gross Weight(kgs)：10
    INTERACE
    Communication Port：RS232/RS485/WIFI/GPRS/LITHIUM BATTERY
    ENVIRONMENT
    Humidity：5% to 95% Relative Humidity(Non~condensing)
    Operating Temperature：-10℃~50℃
    STANDARD
    Compliance Safety：CE
